General Specifications |
|
Output Frequency |
13.56MHz, 27.12MHz, 40.68MHz, 60MHz |
Maximum Output Power (50ohm VSWR 1:1) |
500W |
1,000W |
3,000W |
5,000W |
Output Power Stability (50ohm VSWR 1:1) |
±1% of setting points or ±3W whichever is greater |
Output Linearity (50ohm VSWR 1:1) |
±1% of setting output or ±2W whichever is greater |
Output Power Range |
5~500W |
10~1000W |
30~3000W |
50~5000W |
Output Power Control Mode |
Forward power/Load power control selectable |
Setting Power Resolution |
1W |
Reflected Power Limit |
100W(20%) |
200W(20%) |
600W(20%) |
1000W(20%) |
Frequency Stability |
±0.01% |
Variable Frequency Range |
±5% |
Frequency Tuning Function |
Equipped |
